Beschreibung
| LED-Supply 700mA 2-4 LEDs seriell |
10W (Nominal) |
|
|
|
|
|||
 Constant Current (CC) power Supply for 2-4 Power LEDs. Ideal for FlexiLux Modular, DownLux, ipLux, 3V-3W-Class-Power-LED-Based applications of all LED-Package-Manufacturers (CREE, OSRAM, etc.) |
|||
| Characteristics / Typologie |
2-4 3W-LEDs in Series / seriell IP20 - Indoor / für Innenräume |
||
| Protections / Schutzmassnahmen |
Short, overheat, overload Kurzschluss, Überhitzung, Überlast |
||
| PRI - Input / Eingang |
230V System Input (220-240V) 0.2A Power Factor / Leistungsfaktor > 0.9 |
||
| SEC - Output / Ausgang |
10W Nominal output / Leistung (4 LED à 3W max. 4.2V/LED serial) 9-23V DC System output 700mA / 0.70A Constant Current / Konstantstrom |
||
| Temp. | ta < 45°C (Ambient) tc < 75°C (Case) | ||
| Dimensions / Masse | L x W x H = 111 x 42 x 24mm, <75g (weight in review) |
||
| Labels / Markierungen |            |
||
| Data-Sheet / Datenblatt | - | ||
| Order N° / Bestellnummer / PID |
7530.1070 (auch Ersatz für / replacing 7530.1270) |
||
